Pneumatic Small 380V Plastic Bottle Blow Molding Machine Auto

Name: Pneumatic Small 380V Plastic Bottle Blow Molding Machine Auto
Brand: Sanqing
Price: 1 USD

Brand Name : Sanqing

Model Number : SQ-6

Certification : CE ISO9001

Place of Origin : Hebei, China

MOQ : 1 set

Payment Terms : L/C, T/T

Supply Ability : 30 sets/month

Delivery Time : 45 days

Packaging Details : Angle frame with outside wooden case

Name : Pneumatic Blow Molding Machine, Small Bottles Making Machine

Heating Power : 7.5kW

Voltage : 380V/220V

Plastic Processed : PE/PP/EVA

Warranty : 12 months

Contact Now

Product Name

Pneumatic Blow Molding Machine, Small Bottles Making Machine

Product Description

As a company focus on the blow molding machine for more than two decades, this type of rotary machine is one of our traditional products.

This type of machine has been tested in the market throughout the years, and it has gained good feedbacks from almost all of our customers.

Our Rotary blow molding machine could produce with very high speed output, each hour can reach 3000 pieces of lolly tubes. 5000 pieces of pipette droppers. 1000 pieces above of the milk yogurt juice bottles;

Max. Bottle Containment	800ml
Productive capacity	3000 PCS/hour (ice pops )
Allowed Mould width	125mm
Allowed Mould Thickness	118mm
Blowing Air pressure	0.4-0.7Mpa
Rated Power	15kw
Average Running Power	7kw
Extruder Screw Diameter	55mm
Plasticizing Capacity	40KG/Hour
Size of Main Frame(L.W.H)	3300×1200×1500mm
Weight	1500kg

This 6molds blow molding machine is PLC control , easy operate. The PLC can English languge.

connected style: the blower and extruder is connected to be a whole machine;
separate style: the blower and extruder is separate to be two separate machines;
PLC style: the blower and extruder is conneceted and controlled by PLC touch screen.

Product Tags:

Pneumatic Small 380V Plastic Bottle Blow Molding Machine Auto Images
